Waterjet Pipe Cutting Machine

WPCxxyyA5 series machine is a versatile waterjet pipe cutting system. It cuts pipes with high pressure water jet. This system can be used to cut pipes of various materials especially good for cutting composite material pipes that are not suitable by other types of cutting methods.

WPC -- is the product code for pipe cutting machine.
xx-- the table length (x100 mm). The actual pipe length can be longer than the table length.
yy -- the maximum diameter (x100 mm) of the pipe that can be cut.
A5 -- Max 400 MPa Waterjet pump

The wall thickness of pipe that can be cut depends on the type of material. Cutting speed also depends on the type of the material. Some materials may require adding abrasive to enable the cutting.

The machine system consists of a high pressure water pump, a cutting table with water jet cutting head and abrasive feeding system.

The waterjet pump is 50 hp and when cutting with abrasive, the max thickness of mild steel is 60mm. The pump requires 3 phase electricity power supply of 220V -- 480V, 50 or 60 Hz, (specified by the customer). The pressurized water is fed to the cutting head through a high pressure whip tubing.

The cutting table can rotate the pipe when cutting. The rotation speed is adjustable to suit various cutting speed needs due to different wall thickness and type of the materials. Position of the cutting head is also adjustable to fit different diameters of the pipe. The cutting head can slide along the length of the table to choose desired cutting position. There is an abrasive hopper mounted on the same rail of the cutting head for feeding abrasive to the cutting head. Customer should specify the weight of the pipe when order the machine.

Linear and rotational motions are both CNC controlled with server motors.
